Thermal Imaging Camera Liemke KEILER-25 LRF

Thermal Imaging Camera Liemke KEILER-25 LRF

PRODUCT AVAILABLE ON PRE-ORDER

DELIVERY TIME 10 business days

Liemke Keiler 25 LRF is a thermal imaging camera with a built-in laser rangefinder. Its compact size and simplified operation make it an ideal companion for viewing in forested areas and open terrain. Five modes are available for different heat sources. A powerful VOx ceramic detector with a 12 µm pitch and a resolution of 384 x 288 pixels, digital zoom, and high thermal sensitivity provide a detailed view of the area. Thanks to the integrated laser rangefinder, you can also use the Liemke Keiler 25 LRF to determine the distance to targets up to 600 m at the press of a button. The thermal imaging optics are protected against dust and water ingress in accordance with the IP 66 standard. Live streaming via WiFi is also possible at a distance of up to 20 m, and photos or video recordings can be stored in the 16 GB internal memory.

TECHNICAL SPECIFICATIONS

Objective lens: 25 mm
Detector material: VOx
Detector resolution (pixels): 384x288
Pixel pitch: 12 µm
Frame rate: 50 Hz
NETD: <35mK
Laser rangefinder: range: 600 m
Shutter / calibration: automatic / manual
Display resolution (pixels): 1,280x960 LCOS
Compass and inclinometer
Focus: manual
Digital zoom: 1-4x
Picture-in-picture (PIP): Yes
Field of view: 10.5x7.9 °
Field of view at 100 m in m: 18
Battery: internal
Operating time: 7 hours
Pixel FOV (mRad): 0,48
Weight: 320 g
Video image storage (internal): yes
Memory: 16 GB
Wi-Fi operation: yes
Range: 1250 m
Warranty: 3 years
